DIELECTRIC
介质
|
Polypropylene film
聚丙烯薄膜
|
|
ELECTRODES
电极
|
Vacuum evaporated metal or Alluminum foil
真空蒸镀金属或铝箔
|
|
COATING
包封
|
Encapsulated in reinforced flame retardant plastic case sealed with expoxy
resin meeting the requirement of UL94V-0
阻燃盒子并以环氧树脂灌封
|
|
LEADS
导线
|
Axial leads of tinned wire
径向镀锡导线
|
|
REFERENCE STANDARD
引用标准
|
IEC 384-16； GB 10190-1988
|
|
CLIMATIC CATALOGUE
气候类别
|
40/85/21
|
|
CAPACITANCE VERSUS
RATED VOLTAGE(UR)
静电容量与额定电压
|
0.001µF-2.2µF/100VDC 0.001µF-2.2µF/250VDC
0.001µF-2.2µF/400VDC 0.001µF-2.2µF/630VDC
|
|
CAPACITANCE TOLERANCE
静电容量误差
|
M=±20% K=±10% J=±5%
|
|
DISSIPATION FACTOR
（TANGENT OF LOSS）
散逸因素（损耗角正切）
|
DF≤0.1% (at 20℃ 1KHz)
|
|
VOLTAGE PROOF
耐电压
|
1.6*UR Unit:VDC (5s at 20℃)
|
|
INSULATION RESISTANCE
绝缘电阻
|
C≤0.33µF IR≥30000MΩ; C>0.33µF IR*C≥5000S
（1minute at 20℃ and RH≤65%）
|
|
ENDURANCE
耐久性
|
1000 hours with 125% of rated voltage at 85℃.After the test:
85℃条件下，125%之额定电压1000小时，试验完成后：
△C/C≤5%； △DF≤0.4%
IR ≥50% of the specified value （标称值） (20℃ 1KHz)
|
